consists of: hand shower, overhead shower, shower thermostat, shower hose
overhead shower Croma 280
shower head size overhead shower: 280 x 170 mm
spray type overhead shower: RainAir
ball-joint: overhead shower angle adjustable
maximum flow rate at 3 bar: 8,5 l/min
spray type hand shower: Massage spray, IntenseRain, SoftRain
flow rate of hand shower at 3 bar: 8,5 l/min
minimum flow pressure: 1 bar
max. operating pressure: 10 bar
pipe can be shortened in height
shower bar diameter: 22 mm
height-adjustable slider with locking push-button slider
swivel shower arm
CoolContact thermostat: Prevents the housing from heating up, making showering even safer
thermostat Ecostat E
safety stop at 40°C
adjustable hot water limitation
suitable for continuous flow water heaters
mounting type: exposed installation
centre distance 150 ± 12 mm
intrinsically safe against backflow
pipe length: 1067 mm
2 functions
